What it takes to put the Moon online

A base at the lunar South Pole needs what any town needs: a connection, a map and a clock. These are NASA's own numbers for each, phase by phase.

Every figure carries a tag for its source, like T2 for a table in SCaN's demand signal or UG 4 for a page of the Moon Base User's Guide. Select any tag to see its source. Pick a phase in the bar above.

Prefer to read it straight through? The article version walks through the paper, the phases and how this site was built.

Loading the Moon…
Surface site Relay (schematic) Link Service region

Drag to turn it. The service region and its height are to scale. Site positions, relay orbits and relay counts are schematic, because the paper sets coverage targets, not a constellation design. Older relay requirements start the first zone at 80° S: see how the relays arrive.

The short version: where Phase 3 is headed, 2033 and beyond

1,250+Mbps
relay data rate goal, 25 times the 2028 figure T2
99%
of each day with relay coverage, up from 50% in Phase 1 T2
10m
how precisely you can know where you are on the surface, down from 50 m T3
~150,000kg
of cargo landed in Phase 3, up from about 4,000 kg in Phase 1 UG 4

Dates follow the SCaN paper. NASA's phases page, updated four days earlier, says now to 2029, 2029 to 2032 and 2032 onward. Where the sources disagree

Service altitude T1
Surface sites T1
Assets per site T1
Relay coverage T2
Phase goals UG 4

    Traffic

    Why the network has to grow: more flights, and far more mass on the ground. Every lander, rover and habitat is another user that needs a link, a position and the time.

    Payload to the surface, per phase UG 4

    Approximate kilograms, as the guide rounds them.

    Launches and landings UG 4

    Totals for the selected phase.
    Launches
    Landings
    Payload
    The guide points to nasa.gov/ignition for the current phasing details.

    Crew on the Moon UG 4

    Artemis schedule from NASA's Artemis page, read September 22, 2026 WEB. The Ignition fact sheet describes Phase 3 as “up to 38 tons of cargo per year” FS, a yearly rate beside the guide's phase total.

    Talk

    How much data has to move between the Moon and Earth, and over which links. Early missions talk straight to Earth. Relays in lunar orbit take over as they come online.

    Peak real-time throughput T2

    Megabits per second. Dashed outlines show where the whole program is headed.
    02505007501,0001,250 Mbps
    ┆ Gigabit home fiber, 1,000 Mbps for scale, mine

    Availability T2

    Share of each Earth day the service is up. For relays, that also means a line of sight to the whole service region.
    Relay coverage and availability
    Ground station availability

    Users online at once T2

    Each dot is one user linked at the same moment. "Aggregation" means a surface node gathers everyone's data first and sends it up together.
    High rateLow rate+ means "or more"

    Data per day T2

    Recorded data sent home later, not live.
    Large missions, such as an LRO replacement or Orion. Mostly direct to Earth.
    Small missions, such as commercial landers.

    What Phase 1 is supposed to deliver UG 8

    The User's Guide sets its own communications targets for the first phase.
      For comparison, the SCaN table T2 puts relay throughput at 50 Mbps in 2028 and 550 Mbps in 2032. One is a capability target and the other a demand forecast, so this site shows both and does not try to reconcile them.

      The links themselves

      Radio §III
      On the surface §III
      Every phase §III
      More HD and UHD cameras across the surface, watching spacewalks and construction. Every camera is another user.

      See

      Cameras and sensors in orbit map the ground before anyone lands and keep watching after. The South Pole is hard to image: low sun, long shadows, craters that never see daylight.

      Sharpness T4

      A 2 m × 2 m patch with a 1 m boulder and a 40 cm rock illustrative, mine, drawn at that pixel size. The paper wants pixels under half a metre so small hazards show up.

      How often it looks again T4

      Moon Base region:
      Whole South Pole region:
      One week, 168 hours. Each tick is a pass.

      Also on the list T4

      The base it serves

      The network exists for everything else at the base. These are the guide's Phase 1 targets for the systems that will depend on it, and the place they have to work.

      The place UG 7

      Phase 1 targets, by system UG 8–10

      Build

      The paper ends with the gaps NASA expects companies to help close. Its advice: watch the SCaN website and SAM.gov for upcoming opportunities.

      Companies interested in this work should go to NASA directly: SAM.gov and HQ-MoonBase@nasa.gov UG 15. This site is an independent explainer and is not affiliated with NASA or any bidder.
      Opinion, not from NASA

      What a security engineer notices

      Relays that cannot read your data, a navigation signal that has to prove itself, and why custody matters. My notes, from a career in financial-services security.

      Long-term partnership areas UG 15

      Beyond the immediate gaps, the guide names areas where NASA wants lasting partners.
